Steel Suspension Bridge

Steel Suspension Bridges anogadzirwa neEIHE Steel Structure (EHSS) zvivakwa zvesimbi zvemukati zvinotora simbi yakasimba-yakasimba sezvinhu zvikuru zvinotsigira. Zvigadzirwa zvedu zvinonyanya kushandiswa kuyambuka-gungwa uye kuyambuka nzizi mabhiriji munzvimbo dzeveruzhinji, mabhiriji enzvimbo muzvivakwa zvekutengesa, uye mabhiriji ekumisa ekunze pakati pezvivakwa zveindasitiri. Semutengesi ane ruzivo, takapa zvigadzirwa zvedu kune vakawanda vatengi.

Send Inquiry

Product Description

Inoratidzira simba rakasarudzika, yakanaka ductility uye yakakwirira kuvaka kugona, iyo Steel Suspension Bridge yakagadzirwa nefekitari yedu inonyanya kusanganisira Core components.

Zvikamu	Zvikamu
Superstructure	Main girders/trusses, bhiriji deki, transverse bracing
Substructure	Bridge piers, abutments, mabhengi
Foundation	Murwi hwaro, kuparadzira hwaro
Zvishandiso Zvekubatsira	Railings, mwenje, drainage, majoini ekuwedzera

Application Scenarios

Yedu Steel Suspension Bridge inozvirumbidza yakafaranuka yemaitiro ekushandisa, ine kudiwa kwakasimba munharaunda yeruzhinji. Naizvozvo, zvigadzirwa zvedu zvinonyanya kupihwa kune zvivakwa zvemanisipala, ukuwo kushandira maindasitiri nemapurojekiti ekutengesa.

Scenario	Type
Rwizi-kuyambuka Bridge reExpressway	Simbi Bhokisi Girder Bridge, Simbi Truss Bridge
Rwizi-kuyambuka Bridge reRailway	Steel Truss Girder Bridge, Steel Arch Bridge
Urban Interchange / Ramp	Steel Plate Girder Bridge, Simbi Bhokisi Girder Bridge
Emergency Rescue Access	321 Prefabricated Steel Suspension Bridge
Kuvaka Trestle Bridge	Bailey Bridge (Prefabricated)
Scenic Area Pedestrian Bridge	PB100 Lightweight Modular Bridge
Rural Highway Reconstruction	Diki uye Nepakati-saizi Simbi Plate Girder Bridge

Zvigadzirwa zvedu zvine akawanda mabhenefiti, anosanganisira kusimba kwepamusoro, kureruka kuzvirema, hukuru hwekutenderera, kukurumidza kuvaka kumhanya, kuita kwakanakisa seismic, hunhu hunodzoreka, kudzokorodza uye kushandiswazve. Iyo Steel Suspension Bridge inogadzirwa nefekitari yedu inogamuchirwa zvakanaka nevatengi.

Steel Suspension Bridge

Process Technology

Sechimiro chekunze chakavhurika gore rose, Steel Suspension Bridges anowanzo kuratidzwa nekukukurwa kwemhepo nemvura. Zvivako zvine hurefu hwakaderera zvinogona zvakare kusvibiswa nerwizi kana mvura yegungwa. Muchidimbu, anti-corrosion kurapwa kwakakosha kune zvimiro zvakadaro.

Scenario	Zvishandiso Zvinoshandiswa / Tekinoroji
Inland maguta	Epoxy zinc-rich primer + epoxy micaceous iron oxide yepakati jasi + acrylic polyurethane topcoat
Industrial zones / pamwe nenzizi	Epoxy zinc-rich primer + epoxy micaceous iron oxide yepakati jasi + fluorocarbon topcoat
Nzvimbo dzemahombekombe	Arc kumwaya zingi/aluminium + epoxy sealer + epoxy micaceous iron oxide yepakati jasi + fluorocarbon topcoat
Marine / Deicing Munyu Nzvimbo	Arc kumwaya aluminium + epoxy sealer + epoxy micaceous iron oxide yepakati jasi + fluorocarbon topcoat
Anti-corrosion kune Diki Zvikamu	Kupisa-dip galvanizing
Coating-isina Solution	Weathering simbi

Maitiro akasiyana anokanganisawo kushandiswa kwesimbi chimiro uye mutengo. Kana iwe ukaronga kutenga edu Simbi Kumiswa Bridges, unogona kureva zvinotevera:

Steel Suspension Bridge Type	Steel Structure Consumption(kg/m²)	Yese Mutengo WeSimbi Mamisikirwo(RMB/m²)
Steel Structure Pedestrian Overpass	80 - 120	1,200 - 1,900
Steel Plate Inoumba Girder Bridge	120 - 160	1,800 - 2,600
Simbi Bhokisi Girder Bridge	180 - 240	2,500 - 3,600
Steel Truss Bridge	200 - 280	2,800 - 4,200
Steel Arch Bridge	220 - 320	3,200 - 5,000
Special-shaped / Landscape Steel Suspension Bridge	180 - 280	3,500 - 5,500
Prefabricated Highway Steel Suspension Bridge	140 - 200	2,500 - 4,000
Weathering Steel Suspension Bridge	160 - 240	2,800 - 4,500
Kupfeka kwakajairika (C3)		80 - 150
Conventional Coating (C4)		120 - 200
Hot-dip Galvanizing		200 - 350
Thermal Sprayed Zinc + Fluorocarbon Topcoat (C5)		300 - 500

Tinovimba nemoyo wese kuti simbi yedu Suspension Bridges inogona kugadzirisa matambudziko ako uye kusangana nezvido zvako.

Bata nesu kuti uwane rumwe ruzivo.
